貼標機
圓瓶貼標機
圓瓶貼標機
  • 產品信息

undefined

undefined



主要性能特點

   1)適用于醫藥、食品、日化等行業的圓形物體的半圓及圓周貼標

   2)采用知名品牌馬達驅動,送標速度穩定、可靠

   3)先進親和的人機界面系統,操作簡單直觀、功能齊全,具有豐富的在線幫助功能

   4)自動光電檢測,具備無物不貼標,無標、漏標、斷標自動停機或報警等自動檢測功能,防止漏標和浪費

   5)旋轉式滾壓瓶體,采用彈性棉皮帶,標簽附著更加平整、牢固、無褶皺,大大提升包裝質量

   6)機器結構簡單,緊湊,便于操作及維護

   7)后段可連接流水線,也可配有收料轉盤,便于成品的收集、整理和包裝



  Main performance features

  1)Applicable to label whole curved or half curved surfaces on rotundities from medicinefood,agrochemical and other industries

  2)Using well-known motor drive which ensures a stable and reliable label-feeding speed;

  3)Advanced touch human-computer interface which is easy and  intuitionistic to operate andhas complete functions including abundant online help;

  4)Automatic sensor detection functions including cancelling labeling without objects there and stopping running or raising an alarm without labels to use to avoid omitting or wasting labels;

  5)Rotary rolling depression body adopting elastic sponge-covered belt makes the labels more smooth,firm and with no wrinkles which enhances the packaging quality greatly;

  6)Simple and compact machine construction makes it easy to operate and maintain;

  7)You can also link the back part with assembly line or receiving platform which is convinient for collectingtidying and packaging the finished products.

型號/技術參數Model/ technical  parameters

                 GHR-2510

    貼標速度Labeling speed( pcs / min )

  40-150/分 (與物料及標簽尺寸有關)

   (relate to material and label size

    貼標精度Labeling accuracy(mm)

±1.0mm(不計物料及標簽尺寸)

 (material and label sizes are not counter in

    標簽尺寸Label sizemm

L20-280mm  H30-140mm

    物料尺寸Material sizemm

      Φ20-100mm  H40-120mm

    適用標簽卷內徑Roll inside diametermm

            Φ76mm

    適用標簽卷外徑Roll outerside diametermm

   最大(Max) Φ350mm

    機器尺寸Machine sizemm

 (L2000*W850*H1450mm

    使用電力Power supply

     AC220V  50Hz/60Hz  1500W
