旋蓋機
真空旋蓋機
真空旋蓋機
  • 產品信息



undefined

undefined

undefined

undefined



性能特點:

1)該機適用于帶馬口鐵蓋子的玻璃瓶真空旋蓋,可單獨使用,也可以連接生產線。

2)真空度:設備能達到的極限真空度為-100KPa左右,具體使用與所配置真空泵性能有關。

3)筒式全密封真空室結構,可達到超強的真空室密封效果。因此可以配置較小排量的真空泵即可獲得高真空效果。

4)機器外殼由304不銹鋼材料制作,符合GMP標準。



 Performance feature:

     1) This machine is suitable for vacuum capping for glass bottle with tin lid/cap,can be used alonealso can be connected to production.

     2) Vacuum degree: machine can achieve the ultimate vacuum about-100kpa,depends on the performance of vacuum pump that associated with machine.

3) Cylinder type seal vacuum chamber structure,can achieve super vacuum chamber sealing effect. So you can configure vacuum pump with small displacement and obtain high vacuum effect.

4) Machine shell is made of 304 stainless steel,meets GMP standards.



  技術參數 /  Technical parameter



型號  /Model

GHR-ZX1

GHR-ZX4

真空旋蓋頭數/Vacuum capping head

1

4

瓶身直徑/Bottle body diameter

                      40-100mm

瓶子高度/Bottle height

                     80-180mm

蓋子直徑/Cap diameter

             37-70mm/50-100mm

生產能力/Capacity

6-12 bottles/min

15-30bottles/min

瓶蓋壓強/Cap pressure

67KPa

旋蓋合格率/Capping rate

99%

工作氣壓/Working air pressure

0.4-0.6Mpa

0.6-0.8Mpa

電源/Power supply

1PH.220V/3PH.380V,50/60Hz

功率/Power

1.0KW

2.0KW

凈重/Net weight

350KG

450KG

外形尺寸/Overall dimension

L1580×W700×H1500mm

L1580×W800×H1600mm
